POSEIDON Jetstream Service Manual

JETSTREAM
1.0:E8
Poseidon Jetstream
BREATHING REGULATOR Art. No 3960
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 145 PSI / 10 bar
Air flow ..................................................................................................Approx. 1600 l/min
Inhalation resistance ........................................................................Max. 40 mm of water
Exhalation resistance .......................................................................Max. 20 mm of water
The above data apply when measuring at atmosphere
FIRST STAGE VALVE Art. No 3790, 3790 10
Description...........................................................................................Diaphgram-actuated balanced with shear
venturi boost. Release pressure approx.
217-247 PSI / 1,5-1,7 MPa / 15-17 bar
Connecting threads for primary pressure................................G 5/8’’ -max 4350 PSI /30 MPa /300 bar
accord. SS 2600/K and DIN 477/5 or
yoke connection accord. SS 2603 and
ANSI/CGA V1: 1987
Outlet connections:
One outlet marked R for second stage
(max. airflow).......................................................................................UNF 3/8’’ - secondary pressure
Three outlets marked LP for Jetstream octopus,
drysuits, stadjacket............................................................................UNF 3/8’’ -secondary pressure
Two outlets marked HP for pressure gauge ............................UNF 7/16’’ -primary pressure
SECOND STAGE VALVE Art. No. 2961, 3546
Description...........................................................................................Upstream diaphragm actuated. servo assisted
with safety relief, fixed ejector system.
Purge button for clearing.
Sensivity switch for added control.
REGULATOR HOSE WITH INTEGRAL SAFETY VALVE Art. No 2943
Length....................................................................................................28 inch / 70 cm
Release pressure ................................................................................Approx. 247 PSI/17 bar
TIGHTENING TORQUE
Primary connection, valve cover..................................................22 Ibf.ft / 30 Nm / 3,0 kpm
Connections marked R-LP-HP.......................................................6 Ibf.ft / 8 Nm / 0,8 kpm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
