POSEIDON Jetstream Service Manual

JETSTREAM
1.0:E9
Poseidon Oceanair
BREATHING REGULATOR Art. No 2940
USA: Poseidon Thor
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 181 PSI / 12.5 bar
Air flow ..................................................................................................Approx. 1500 1/ min
Inhalation resistance ........................................................................Max. 40 mm of water
Exhalation resistance .......................................................................Max. 20 mm of water
The above data apply when measuring at atmospheric pressure
FIRST STAGE VALVE Art. No 3020
Description...........................................................................................Diaphgram-operated, compensated
Connection threads for primary pressure................................G 5/8’’ -max 4300 PSI / 300 bar accord.
SS 2600/K and DIN 477/4
Outlet connections:
Four outlets marked LP for second stage,
drysuits, hookah supply, safety second stage, etc.................UNF 3/8’’ -secondary pressure
One outlet marked HP for pressure gauge..............................UNF 7/16’’-primary pressure
SECOND STAGE VALVE Art. No. 2961, 3546
Description...........................................................................................Upstream diaphragm actuated. servo assisted
with safety relief, fixed ejector system.
Purge button for clearing.
Sensivity switch for added control.
REGULATOR HOSE WITH INTEGRAL SAFETY VALVE
Length.................................................................................................... 28 inch / 70 cm
Release pressure ................................................................................ Approx. 247 PSI/ 17 bar
TIGHTENING TORQUE
Primary connection ..........................................................................20-22 Ibfft 28 Nm
Valve cover ...........................................................................................20-22 Ibf.ft 28 Nm
Connections marked LP-HP...........................................................6 Ibf.ft / 8 Nm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
