Powtran PI8600 Series User Manual

Section VII Standard Specifications
104
Section VII
7-2. Standard specification
Items
Specifications
Power
Voltage and frequency
Single-phase 200~240V, 50/60Hz
Three-phase 200~240V, 50/60Hz
Three-phase 380~415V, 50/60Hz
Allowable Fluctuation range
voltage: ±15% frequency: ±5%
Control
Control system
high performance vector control inverter based on 32 bit
DSP
Output frequency
G/F type: 0.00~800.0Hz, maxmum frequency can be set
between 10.00 and 800.0Hz
control method
V/Fcontrol
control method
V/Fcontrol
Start torque
0.50Hz 180%
Start torque
0.50Hz 180%
speed adjustable range
1：100
speed adjustable range
1：100
Speed stabilizing precision
±0.5%
Speed stabilizing precision
±0.5%
waveform produce methods
Asynchronous space vector PWM, N-class subsynchronous
space vector PWM, two-phase optimization of space vector
PWM.
Auto torque boost function
Achieve low frequency (1Hz) and high output torque
control under V.F control mode.
Accelerate / decelerate
control
Sub-set S curve acceleration and deceleration mode ,
maximum acceleration and deceleration time is 3200 days
Long running time control
16 segments speed run,maximum running time is 3200 days
frequency setting accuracy
Digit: 0.01Hz(below 300Hz), 0.1Hz(above 300Hz);
alalogue: 1% of maxmum frequency
frequency accuracy
Speed control tolerance 0.01%(25℃±10℃).
V/F curve mode
Linear, 1.2 times the power, 1.7 times the power, 2 times
power, user-set 8 V / F Curve.
Over load capability
G type: 150% rated current -1 minute, rated current
200% -0.1 second;
F: rated current 120%-1 minute,150% of rated current-0.1
second;
slip compensation
V / F control can automatically compensate for
deterioration.
Running
Running method
Keyboard/terminal/communication
Starting signal
Forward, reverse, jog (parameter control direction),forward
jog, and reverse jog.
Emergency stop
Interrupt controller output.
fault reset
When the protection function is active, you can automatically
or manually reset the fault condition.
