Powtran PI8600 Series User Manual

Section V Parameter Function Table
22
Section V
parameters, obtain high-performance control effect; suitable for a inverter driving a motor
occasions; suitable for a inverter driving multiple motors occasions; suitable for the inverter
as a variable frequency power supplies.
1 : Sensorless vector control
High-performance speed sensorless vector control; need to set the appropriate electrical
parameters or the motor parameter tuning; truly achieved the decoupled AC motor, so that
operational control of DC motors.
2 : Sensor feedback close loop vector control
Suitable for high precision speed control occasions, need to install PG card and pulse
encoder shaft in the motor or mechanical equipment.
F01
Keyboard setting frequency
Lower frequency~upper frequency
Hz
50.00
Y
The keyboard for a given operating frequency,it can be any frequency between lower
frequency and upper frequency .
F02/F03setting to 0, Involved in setting frequency calculation.
F02
Frequency main set mode
Keyboard setting frequency
or RS485
0
-
0
Y
AI1 the external analog
setting
8000
1
AI2 the external analog
setting
2
AI3 the external analog
setting
3
Keyboard potentiometer
setting
4
Multi-segment digital
voltage setting
5
Digital Pulse Setting
6
The main mode of the frequency running frequency:
0 : keyboard setting frequency or RS485 change F01 keyboard setting frequency
Multi-digital voltage terminal effective exchange, change F01keyboard setting value
1 : AI1 the external analog setting
Given the external analog0~10V,-10V~+10V,0~20mA.For detail please read the o group
parameter.
2 : AI2 the external analog setting
3 : AI3 the external analog setting
Given the external analog 0~10V, 0~20mA. For detail please read the o group parameter.
4 : Keyboard potentiometer setting
Keyboard potentiometer setting, keyboard potentiometer for a given start and end values of
the corresponding values can be positive role and negative effects. For detail please read the
A group parameter.
5 : Multi-segment digital voltage setting
o36~o46 IO input terminal function set to 11, 12, 13, switch H47~H54 Multi-digital voltage
setting, 100% Corresponding to the maximum frequency .
