6 : Digital pulse setting
Digital pulse input frequency Corresponding to the setting frequency, For detail please read
the o52 group parameter.
Pulse input terminal and DI8 terminal reset , after using the digital pulse input,o43 set to
0 ,Otherwise, the function settings will take effect, the pulse input on status of o58 can be
checked, be limited to low-speed pulse.
Through o36~o46 IO input teminal set to 14, 15, 16 be configured to switch the source
Auxiliary setting mode of frequency set:
0 : Keyboard frequency setting frequency or RS485, change F01 kayboard setting frequency
After multi-digital voltage terminal effective switch, change F01keyboard setting.
1 : AI1 the external analog setting
Given the external analog0~10V,-10V~+10V,0~20mA.For detail please read the o group
parameter.
2 : AI2 the external analog setting
Given the external analog 0~10V, 0~20mA.For detail please read the o group parameter.
3 : AI3 the external analog setting
Given the external analog 0~10V, 0~20mA.For detail please read the o group parameter.
4 : Keyboard potentiometer setting
Keyboard potentiometer setting, keyboard potentiometer for a given start and end values of
the corresponding values can be positive role and negative effects. For detail please read the
A group parameter.
5 : Multi-segment digital voltage setting
o36~o46 IO input terminal function set to 11, 12, 13, switch H47~H54 Multi-digital
voltage setting, 100% Corresponding to the maximum frequency .
6 : Digital pulse set
Digital pulse input frequency corresponding to set the frequency, For detail please read o52
parameter.
Pulse input terminal and DI8 terminal reseting, After use digital pulse input, o43set to 0,
Otherwise, the function settings will take effect, can check the pulse input status o58, be
