Powtran PI8600 Series User Manual

Section V Parameter Function Table
36
Section V
100 bit
Acceleration time:*s
0
Acceleration time:*min
1
Acceleration time:*h
2
Acceleration time:*day
3
1000bit
Deceleration time:*s
0
Deceleration time:*min
1
Deceleration time:*h
2
Deceleration time:*day
3
1 bit: Acceleration time adjustment mode
0
No adjustment of acceleration
time
No adjustment
1
AI1 adjustment of the
external analog giving
8000
-
2
AI2 adjustment of the
external analog giving
Actual acc. time = Acc. time*AI2 giving percentage
3
AI3 adjustment of the
external analog giving
Actual acc. time = Acc. time*AI3 giving percentage
4
Adjustment of keyboard
potentiometer giving
Actual acc.time = Acc. time*keyboard potentiometer
giving percentage
5
Adjustment of multi steps
digital voltage giving
Actual acc.time=Acc.time*multi steps digital voltage
giving percentage
10 bit: Deceleration time adjustment mode
0
No adjustment of
acceleration time
No adjustment
1
AI1 adjustment of the
external analog giving
8000
-
2
AI2 adjustment of the
external analog giving
Actual acc. time = Acc. time*AI2 giving percentage
3
AI3 adjustment of the
external analog giving
Actual acc. time = Acc. time*AI3 giving percentage
4
Adjustment of keyboard
potentiometer giving
Actual acc.time = Dec. time*keyboard potentiometer
giving percentage
5
Adjustment of multi steps
digital voltage giving
Actual acc.time=Dec.time*multi steps digital voltage
giving percentage
100, 1000 bit: The unit of Acc. and Dec time when program running on 0 step spe
Acc. and dec. time
1000 bit 100 bit
Range(e.g. F09, F10=3200.0)
*s
0
3200.0 S
*Min
1
3200.0 Min
*H
2
3200.0 H
*Day
3
3200.0 Day
F49
Running
configuration
1 bit
Running direction: forward
0
-
0000
N
Running direction: reverse
1
