Powtran PI8600 Series User Manual

Section V Parameter Function Table
47
Section V
4
Adjustment of potentiometer
giving
Actual UP adjustment ratio= percentage given by
A41* potentiomet
5
Adjustment of multi-steps digital
voltage
Actual UP adjustment ratio=percentage given by
A41* multi-steps digital voltage
1000 bit: DN adjustment mode of adjusting speed ratio
0
N adjustment of acceleration time
No adjustment
1
AI1 adjustment of the external
analog giving
8000
-
2
AI2 adjustment of the external
analog giving
Actual DN adjustment ratio =percentage given by
A42*AI2
3
AI3 adjustment of the external
analog giving
Actual DN adjustment ratio=percentage given by
A42*AI3
4
Adjustment of potentiometer
giving
Actual DN adjustment ratio=percentage given by
A42*AI3.
5
Adjustment of multi-steps digital
voltage
Actual DN adjustment ratio=percentage given by
A42*multi-steps digital voltage.
A40
UP/DN adjustment value
-300.00~300.00
-
0.00
N
Frequency after adjustment＝set frequency + UP/DN adjustment value.
A41
UP adjustment ratio
0.01~20.00
Hz
0.01
Y
Fix speed: To increase frequency every 200ms.
Fix times: To increase frequency every triggering.
A42
DN adjustment ratio
0.01~20.00
Hz
0.01
Y
Fix speed: To reduce frequency every 200ms.
Fix times: To reduce frequency every triggering.
A43
A44
The definition of
multifunction keys MF1
and MF2
MF is defined as adding
function key
0
-
-
0
1
Y
Y
MF is defined as reducing
function key
1
MF is defined as free
stopping key
2
MF is defined as FWD
running key
3
MF is defined as REV
running key
4
MF is defined as forward
JOG function key.
5
MF is defined as reverse
JOG function key.
6
MF is defined as JOG
function key.
7
MF is defined as UP
function key
8
