Powtran PI8600 Series User Manual

Section V Parameter Function Table
48
Section V
MF is defined as Down
function key.
9
UP / DN adjusted value
reset
10
keyboard potentiometer
setting value reset
11
Define a customer defined function key.
0： MF is defined as a plus function key
In monitoring the menu, add function keys a set of keyboard F01 frequency plus changes.
In menu of parameter selection, add function keys adjust the parameter choosen.
Modify the parameter of the menu, add function keys adjust the parameter values.
1： MF is defined as a decrease function key
In monitoring the menu, add function keys a set of keyboard F01 frequency decrease changes.
In menu of parameter selection, add function keys adjust the parameter choosen.
Modify the parameter of the menu, add function keys adjust the parameter values.
2： MF is defined as a freedom stop function key
Monitoring the menu，Parameter select a menu of the key to effectively，frequency inverter
parking stopped.parking stopped freely，no start function will running again in 1s .
3： MF is defined as FWD function key.
Monitoring the menu and select the menu, the key will running in FWD.
4： MF is defined as REV function key.
Monitoring the menu and Parameter select a menu of the key effectively, the frequency
inverter will running in REV.
5： MF is defined as move the function keys
Monitoring the menu and Parameter select a menu of the key effectively, the frequency
inverter will running on the dot.
6： MF is defined as against the function keys
Monitoring the menu and Parameter select a menu of the key effectively, the frequency
inverter will running on the jog.
7： MF is defined as jog function key
Monitoring the menu and Parameter select a menu of the key effectively, the frequency
inverter will running in jog.Running direction is decisioned by F35 unit setting and terminal
status
8： Mfisdefined as Up function key
Any moment the button effectively，frequency invertger Up control，control parameter
A38
~
A42 decision.
UP/Dn function effectively set A38 kilobit=1.
9： Mfisdefined as Down function key
Keybaord effectively anytime ，frequency inverter Down control ，parameter can be control
A38~A42 decided.
UP/DN Functions effectively to set A38 kilobit=1.
10：Mfis defined UP/DN
regulate clearance
A40
UP
/Dn regulate clearance，Electrical level trigger.
11：MF keyboard potential is defined as the set value
A47 keyboard potentiometer setting point clearance,Electrical level trigger.
A45
Potentiometer X1
0~100.00
%
0.00
Y
The starting point of keyboard potentiometer
A46
Potentiometer X2
0~100.00
%
100.00
Y
The end point of keyboard potentiometer
A47
The value of keyboard
0.0~100.00
%
-
Y
