Powtran PI8600 Series User Manual

Section V Parameter Function Table
63
Section V
UP/DN regulate clearance
66
Keyboard potentiometer
setting clearance
67
External fault signal
input (edge)
68
Setting
value
Output connect
Explation
0
No function
No function
1
FWD
FWD,can set to edge trigger or level trigger.
2
REV
REV,can set to edge trigger or level trigger.
3
Three-wire running STOP
o35 set three-wire running,STOP function.
4
Multistage speed command 1
Combine 16 step multi-step setting.Detail
H parameter system
5
Multistage speed command 2
6
Multistage speed command 3
7
Multistage speed command 4
8
Multistage acceleration command 1
Combine 8 step acceleration setting.Detail
H parameter system
9
Multistage acceleration command 2
10
Multistage acceleration command 3
11
Multistage digital voltage 1
Combine degital voltage setting.Detail H
parameter system
12
Multistage digital voltage 2
13
Multistage digital voltage 3
14
frequency setting main way 1
Combine frequency setting main way
switch.Detail F parameter system
15
frequency setting main way 2
16
frequency setting main way 3
17
frequency setting assistant way 1
Combine frequency setting assist way
switch.Detail F parameter system
18
frequency setting assistant way 2
19
frequency setting assistant way 3
20
MSS timing running 1
Combine 8 step time setting.Detail H
parameter system
21
MSS timing running 2
22
MSS timing running 3
23
Running control mode switch 1
Combine running control mode switch.
Detail F05 parameter system
24
Running control mode switch 2
25
Running control mode switch 3
26
FWD torque up limit switch 1
Combine FWD torque upper limit switch.
