Powtran PI8600 Series User Manual

Section V Parameter Function Table
69
Section V
Output voltage
4
DC bus voltage
5
IGBT temperature
6
Output frequency
7
Output rpm
8
Torque actual value
9
o63
SPA pulse output rate
1~1000
-
1
Y
o64
SPB pulse output rate
1~1000
-
1
Y
SPA, SPB provide two isolated pulse output signal can be analogical multiple analog output
signals.
SPA, SPB provide high speed pulse output function. Set by o61~o64 and set functions valid
when inverter power on again.
SPA corresponding output signal 1, this function selected, o21 DO1 output action is invalid.
SPB corresponding output signal 2, this function selected, o22 DO2 output action is invalid.
Pulse output ratio = 1, output signal range 0 ~ 50hz.
Maximum pulse output frequency 50 Khz, minimum frequency 1hz.
for example
SPA pulse output options = 2 Actual frequenciy ;
SPA pulse output options = 10
The actual output pulse frequency = actual frequency / maximum frequency * 50hzx10.
SPA pulse output options =3 Actual current
SPB pulse output ratio=20
The actual output pulse frequency = actual current percentage 200*50hz*2
Output
Set
Value
Output Signal Range Definition
No action
0
No output
Set frequency
1
0~Max frequency
Actual frequency
2
0~Max frequency
Actual current
3
0~200%, corresponding paramerter: S03
output current percentage
Output voltage
4
0~200%, correlation parameter: b02、b15
motor rated voltage
Bus voltage
5
0~1000V DC voltage
IGBT temperature
6
0~100.0℃
Output power
7
0~200%
Output torque
8
0~Max torque
Actual torque
value
9
0~200% torque
o65
o66
Limit time 1
configuration
Limit time 2
configuration
1 bit
Boot time
0
-
-
0000
0000
Y
Y
Running timing
1
10bit
Reserved
-
