o54
Preset count value for a
given
0~o55
-
0
Y
o55
Max count value for a
given
o54~9999
-
9999
Y
The correspondind indication of Yi terminal when input pulse signal count reach the preset value.
1、DiX（X=1~6）terminal to set “pulse count input”；and set o54、o55：
DiX（X=1~6）terminal to set pulse counter clear,terminal act to clear the count zero.
DiX（X=1~6）terminal to set loading with preset value. The counter will load preset value.
DiX（X=1~6）terminal to set loading with upper value. Terminal act to load upper value.
DiX counting
o21
o22
0
1
2 3 4 5 6 3 4 5 6 3
o54
o55
T
T
the thousand of O51 set t
o55
T
o54
T
2、o21~o24 output signal option
o21 preset value reach,after reached upper value,the output signal valid time set byo51.
o22 upper count value reach, after reach upper value the valid time of output signal set by
o51.
The frequency range of counter pulse signal：0~100Hz
o56
Analog terminal valid option
0000~F7FF
-
0000
Y
This parameter is used to choose analog terminal function valid of each terminal.
Set 0~10 bit
Analog terminal valid option
0
Actual terminal valid
1
Analog terminal valid
15 14 13 12 11 10 9 8
7
6
5 4
3 2 1 0
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
14 13 0123
45
6
7
89101112
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8AI1
AI2
AI3
15
O4
O3
O2
O1
leave unused
o57
DI1~4 terminal status
0000~1111
-
-
Y
o58
DI5~6 terminal status
0000~1111
-
-
Y
o59
AI2~3terminal status
000~111
-
-
Y
o60
O1~4 terminal status
0000~1111
-
-
Y
It can search terminal status that set actual terminal valid.
It can change terminal status that set analog terminal valid.
o61
o62
SPA pulse output
SPB pulse output
No action
0
-
-
0
0
Y
Y
Set frequency
1
Actual frequency
2
Actual current
3
