Powtran PI8600 Series User Manual

Section V Parameter Function Table
67
Section V
10 bit
reloading after the count
value reaches maximum
0
count is cleared after the
arrival maximum
1
100 bit
Reload after power on
0
Be cleared after powter on
1
Keep count after power on
2
1000bit
Counting period
0
Output signal valid time
20ms
1
Output signal valid time
100ms
2
Output signal valid time
500ms
3
0 bit：Counting mode of control
0 Recycle count:the count value reaches maximum，Pulse output to reach（output terminal
to set）.
1 Single circle count:the count value reaches maximum，Pulse output to reach , stoprunning.
10 bit：count value reaches maximum to act under recycle mode.
0 Reload
1 Clear to zero.
100 bit：to define the status of counter after power on.
0 Reload after power on.
1 Clear to zero after power on
2 Keep formal status after power on.
1000 bit：define o21~o24 as the delay time of output signal of preset value reach or upper
value reach.
0 Counting period: when reach this value，to keep output statuse valid，until count value
change.
1 Output signal valid time 10ms，when reach this value, keep output status valid 10ms.
2 Output single valid time 100ms，when reach this value, keep output status valid 100ms.
3 Output single valid time 500ms，when reach this value, keep output status valid 500ms.
o52
Maximal pulse input
frequency
0.1~50.0
KHz
20.0
Y
This parameter define maximal pulse input frequency of analogy setting.
This input signal frequency is high, so it should be set by multifunctional terminalDI6.
Max input pulse frequency corresponding to analogy maximal input upper.
Pulse input frequency analog set，max input pulse frequency o52 corresponding to max
output frequency F12.
Pulse input frequency f_pulse correspondint to set frequency f_set calculate formula ：f_set
＝f_pulse/o52*F12.
Pulse input analog giving, max input pulse frequency o52 corresponding to 100.0%.
Pulse input frequency f_pulse corresponding analog formula of p_set：p_set＝
f_pulse/o52*100.0%.
o53
The current counter status
0~9999
-
0
Y
