Powtran PI8600 Series User Manual

Section V Parameter Function Table
71
Section V
1000 bit: Set running time of defined program running
0: Running-time decided by the H18 ~ H25
1: Running time decided by terminal
H01
Program running
configuration
1 bit
Sequence control
0
-
0710
Y
Terminal control
1
10 bit
Program running start
segment
0~15
100 bit
Program running end
segment
0~15
1000bit
Output signal valid time
8ms
0
Output signal valid time
20ms
1
Output signal valid time
100ms
2
Output signal valid time
500ms
3
1 bit: program run control mode
0: Sequential control
Run automatically according to the start segment,end segment and program running time of
program running.
You can use o36 ~ o46 switchover next function , switchover to the next program running .
1: Terminal control
Use multi segment control terminal o36 ~ o46 multi segment instruction 1, 2, 3, 4, Control
program segment, running time arrives,Running based on the 0 paragraph speed. After Multi
- stage speed control terminal switchover, reevaluate running time
Do not use of multi - stage speed control terminal o 36 ~ o46 multi - speed instruction, You
can use o36 ~ o46 switchover next function. The terminal control for single trigger, triggered
once, program running to next paragraph, running time recalculated.Running time of arrival,
Running based on the 0 paragraph speed.
10 bit: Defining the start running of the Program
100 bit: Defines the end of the program period
1000 bit: Define effective time of the program output signal
H02
Program running
mode
1 bit
Single-cycle
0
-
0000
Y
Continuous cycle
1
One-cycle command
running
2
10 bit
The zero speed running
when pause
0
Fixed-speed running
when the suspension
1
100 bit
Stop with the parameters
set when stop
0
Stop with the settings of
start up
1
1000bit
Running at the speed
when start up segment
0
