Powtran PI8600 Series User Manual

Section V Parameter Function Table
90
Section V
C12
High speed slip switching
frequency
C10~Max frequency
Hz
30.00
Y
High speed segment slip compensation switching frequency
C13
Upper froward torque
0.0~300.0
%
250.0
Y
The parameter is a ratio，setting value is 100%. Responding to motor rated output torque.
Set forward torque mode through C15.
In speed control mode, it‟s upper forward torque.
In torque control mode, it‟s forward torque setting value.
C14
Upper reverse torque
0.0~300.0
%
250.0
Y
The parameter is a ratio，setting value is 100%.
Set reverse torque mode through C16.
In speed control mode, it‟s upper reverse torque.
In torque control mode, it‟s reverse torque setting value
C15
Forward torque
setting mode
1 bit
Setting
mode
Set by keyboard
or RS485
0
-
0000
Y
AI1 external
analogy
giving
8000
1
AI2 external
analogygiving
2
AI3 external
analogygiving
3
Keypad
potentiometer
giving
4
Multi-step digital
voltage giving
5
Digital pulse set
6
10bit
direction
Direction
uncontrolled
0
Direction
controlled
1
C16
Reverse torque
setting mode
1 bit
Setting
mode
Set by keyboard
or RS485
0
-
0000
Y
AI1 external
analogy
8000
1
AI2 external
analogy giving
2
AI3 external
analogy giving
3
Keypad
potentiometer
giving
4
Multi-step digital
5
