Powtran PI8600 Series User Manual

Section V Parameter Function Table
91
Section V
Digital pulse set
6
10bit
direction
Direction
uncontrolled
0
Direction
controlled
1
C17
Torque set gain
0.0~300.0
%
200.0
Y
C15 1 bit：Setting mode
C16 1 bit：Setting mode
0
Set by keyboard or RS485
Responding to C13/C14
1
AI1 external analog setting
8000
-
2
AI2 external analog setting
As per AI2 external analog setting
3
AI3 external analog setting
As per AI3 external analog setting
4
Keyboard potentiometer setting
As per keyboard potentiometer setting
5
Multi segment digital voltage setting
As per multi segment digital voltage setting
6
Digital Pulse Setting
As per digital pulse setting
While the unit digit of C15,C16 is 1~6, the upper torque of C13,C14 is for checking.
C15 10 bit: Direction Control
C16 10 bit: Direction Control
0: No control Direction
Direction is controlled by terminal or keyboard
1:Control Direction
Setting value of forward torque > setting value of reverse torque, forward direction.
Setting value of forward torque < setting value of reverse torque, reverse direction.
C13 upper forward torque =setting value percentage * C17 torque given gain.
C14 upper reverse torque =setting value percentage * C17 torque given gain.
Example:
C15 forward torque setting way=4 keyboard potentiometer setting.
C16 reverse torque setting way=4 keyboard potentiometer setting.
Forward/reverse both can control direction, C15=0x14，C16=0x14.
Potentiometer corresponding setting value A48=-100%，A49=100%
Keyboard potentiometer set A47=100%，C17=200.0%
C13 forward upper torque =100%*200.0%=200.0%, control direction forward 200% torque
Keyboard potentiometer set A47=100%，C17=200.0%
C14 upper reverse torque =100%*200.0%=200.0%, control direction reverse 200% torque
C18
Speed /torque control shift
Speed control
0
-
0
Y
Torque control
1
F00 control method is to s select senseless vector control or sensor feedback close loop
vector control can change speed or torque control through input terminal. After setting IP
terminal change, keyboard set invalid, only for query.
C19
Upper speed
setting mode
1 bit
Separate
setting
mode
keyboard or
RS485 setting
0
-
0000
Y
AI1 external
analog
8000
1
