Powtran PI8600 Series User Manual

Section V Parameter Function Table
92
Section V
AI2 external
analog setting
2
AI3 external
analog setting
3
Keyboard
potentiometer
setting
4
Multi-segment
digital voltage
setting
5
Digital pulse
detting
6
10bit
selection
C19 unit bit
setting
0
S00 detting
grequency
1
C20
Upper speed
0.00~Max frequency
-
50.00
Y
While torque control, setting upper speed
C19 1 bit: Separate setting mode
0
keyboard or RS485 setting
As per C20 setting
1
AI1 external analog setting
8000
-
2
AI2 external analog setting
As per AI2 external analog setting
3
AI3 external analog setting
As per AI3 external analog setting
4
Keyboard potentiometer setting
As per keyboard potentiometer setting
5
Multi-step digital voltage setting
As per Multi-step digital voltage setting
6
Digital Pulse Setting
As per Digital Pulse Setting
While the unit digit of C19 is 1~6, the upper speed of C20 is for checking
C19 10 bit; Select upper speed setting Ways
0: Separate setting, as per the selection of C19 unit digit
1:Setting frequency is according to S00,and affected by the following parameters.
F02 frequency main setting mode / F03 auxiliary setting mode of frequency /F04 between
main and auxiliary setting frequency
C21
Torque acceleration time
0.0~200.0
s
1.0
Y
C22
Torque deceleration time
0.0~200.0
s
1.0
Y
C21, C22 torque acceleration time, turning moment deceleration torque control mode and
effective
Torque acceleration time, torque accelerated from 0 to 300 hours
Torque speed, torque, from 300 down to 0.
C23
Low speed excitation
compensation
0~100
%
30
Y
Under low speed, compensate excitation quantity, increase torque feature, in case of meeting
the requirement, try to make it lower, could reduce the motor heating up caused by magnetic path
full.
