PR electronics 5511 User Manual

48 49
Temperature coefficient:
Type E,J,K,L,N,T,U:
span < 500°C ....................................... ±0.05°C / °Camb.
span > 500°C ....................................... ±0.01% of span / °Camb.
Type B,R,S,W3,W5 ...................................... 0.2°C / °Camb.
Sensor error detection ................................ Yes
RTD input:
Max. offset .................................................. 75% of selected max. value
Cable resistance per wire (max.) ................. 50 Ω
Sensor current ............................................. Nom. 0.4 mA
Basic accuracy ............................................ ±0.2°C
Temperature coefficient
span < 100°C ....................................... ±0.01°C / °Camb.
span > 100°C ....................................... ±0.01% of span / °Camb.
Effect of sensor cable resistance
3- / 4-wire .................................................... < 0.002 Ω / Ω
Sensor error detection ................................ Yes
Linear resistance input:
Measurement range .................................... 0...5 kΩ
Min. measurement range (span)
2- / 4-wire ............................................ 10 Ω
3-wire and difference ........................... 50 Ω
Max. offset .................................................. 75% of selected max. value
Max. cable resistance per wire ................... 50 Ω
Sensor current ............................................. Nom. 0.4 mA
Effect of sensor cable resistance
3- / 4-wire .................................................... < 0.002 Ω / Ω
Sensor error detection ................................ Yes
RTD Min. Max. Min.
type temperature temperature span Standard
Pt -200°C +850°C 25°C IEC 60751
Ni -60°C +250°C 25°C DIN 43760
Voltage input:
Measurement range .................................... -240...+240 VDC
Min. measurement range (span) ................. 20 mV
Max. offset .................................................. 75% of selected max. value
Input resistance (Vin ≤ 2.4 V) ..................... Nom. 10 MΩ
(Vin > 2.4 V) ..................... Nom. 5 MΩ
Bridge input:
Measurement range .................................... -70...+70 mV
Min. measurement range (span) ................. 5 mV
Max. offset .................................................. 75% of selected max. value
Input resistance ........................................... Typ. 500 kΩ
Current input:
Measurement range .................................... -100...+100 mA
Min. measurement range (span) ................. 2 mA
Max. offset .................................................. 75% of selected max. value
Input resistance ........................................... Nom. 10 Ω + PTC 10 Ω
Cable breakage detection (4...20 mA) ........ Yes
Electrical specifications - output:
Current output:
Signal range ................................................ -20...+20 mA
Min. signal range (span) .............................. 5 mA
Max. offset .................................................. 75% of selected max. value
Load (max.) .................................................. 20 mA / 600 Ω / 12 VDC
Load stability ............................................... < ±0.01% of span / 100 Ω
Current limit ................................................. 23.5 mA
Voltage output:
Signal range ................................................ -10...+10 VDC
Min. signal range (span) .............................. 0.25 VDC
Max. offset .................................................. 75% of selected max. value
Load (max.) .................................................. 10 VDC / 20 mA
Current limit ................................................. 40 mA
Voltage limit ................................................. 11.5 VDC
