PR electronics 5511 User Manual

52 53
MECHANICAL SPECIFICATIONS:
98 mm
102 mm
6 mm
10
mm
1 mm
42
mm
42 mm
88 mm
48 mm
96 mm
2.5 mm
91.5 mm
44.5 mm
BACKPLATE
FRONT
PANEL CUTOUT
FRONT
Max.
HARDWARE PROGRAMMING:
DP2: Auxiliary voltage SW ON SW OFF
Loop supply 2 1
8 V excitation 1 2
2.5 V ref. - 1, 2
DP1: Analogue output SW ON SW OFF
Output ±20 mA 4 1, 2 , 3
Output ±10 VDC 1, 3, 4 2
Output ±1 VDC 1, 2, 3 4
FRONT LAYOUT
TERMINAL PLACEMENT
