DIAGNOSTIC TEST TEST DESCRIPTION
INCLINE TEST
menu: MACHINE TEST > INCLINE TEST
Test parameters:
• A/D
1
- lift motor incline position potentiometer A/D number.
• SEC - UP/DWN command response delay between the
UPCA
2
and LPCA
3
.
• Glitches - Momentary failures in the A/D potentiometer out-
put. If there are more than 50 Glitches, the lift motor should be
replaced.
.
STOP KEY TEST
menu: MACHINE TEST > STOP KEY TEST
(P10, P30 consoles only)
Verifies the Stop Key and E-Stop function
Test sequence steps:
1.StopKey test - Press the Stop Key
2.Lanyard ESTOP
4
test- Pull the lanyard to trip the emer-
gency stop function.
3.Exit test - Press the Stop button to reset and exit test.
(1)Only included on products that have the ASLfeature.
(2)Not included on the EFX600 series or TRM600 series products.
Club Settings Menu (5651565)
Service Access Code: 5651565 (see "Service Menu Access Codes" on page28)
Used to customize the equipment user interface localization, Workouts configuration, and
maintenance default settings.
menu: Club Settings (51765761) > DIAGS - CLUB SETTINGS
1
analog to digital converter
2
Upper PCA board
3
Lower Printed Circuit Assembly board; also refered to as the Lower PCA or simply as the
lower board. On treadmills, it is the console to base function interface and the motor con-
troller unit (MCU). On self-powered units, it is the lower PCA console to base function inter-
face.
4
Emergency Stop: Safety clip and lanyard attached to the stop switch to immediately turn
off power bringing the treadmill to a stop.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 39
4 Standard Service Menus
LED Console Standard Service Menus
