Drive Belt Replacement
About
This procedure provides instruction to remove and install the Drive Belt for both the legacy
and common frame weldment machines
Note:Common & Legacy Frame information, see TRM600/700/800 Common
Frame Overview.
Procedure
There are separate procedures for the legacy and common frame machines:
l Legacy Frame, see "Legacy Frame Drive Belt Replacement" below
l Common Frame, see "Common Frame Drive Belt Replacement" on page149
Legacy Frame Drive Belt Replacement
Review entire procedure before starting.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 142
6 Replacement Procedures
Drive Belt Replacement
