Trim Side Cover Replacement
Trim Side Cover Replacement
ID Description
Trim Side Cover - left
Trim Side Cover - right
Removal Instructions
Repeat the removal procedure for both the left or right side trim covers.
1. Remove the hood cover, see "Hood Cover Replacement" on page88.
2. Remove the trim landing cover, see "Covers and Panels Replacement" on page86.
3. Remove the trim end cap covers, see "Trim End Cap Covers Replacement" on
page97.
4. Remove the hood transition cover, see "Covers and Panels Replacement" on
page86.
5. Starting from the front moving reward, use a standard flat blade screwdriver to
release (unsnap) the top of the trim side cover from five anchor mount clips. Hold
cover while releasing the upper anchor bracket clips and then pull down and away
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 101
6 Replacement Procedures
Covers and Panels Replacement
