Specification
System Component Specification
Ammeraal Beltech brand running belt tension (PPP000000303765103)
(2)
3.75 (0.75%)
(1)
Forbo brand running belt tension (PPP000000302449101 or
PPP000000036355141)
(3)
3.55 (0.55%)
(1)
Notes:
1.Referenced to gauge reading 3.0 (0.0%)
2. The Ammeraal Beltech brand running belt must NOT be used with a pre-waxed deck.
3. The Forbo brand running belt must be used with a pre-waxed deck.
Procedure
CAUTION: 1) The tracking adjustments should only be done in 1/4 turn incre-
ments.
2) ONLY use the right side tension bolt to adjust tracking.
3) ONLY use hand tools to adjust tracking.
Running belt tension adjustment
CAUTION: 1) ONLY use hand tools for belt tension adjustment.
2) Final belt tension adjustments should only be done in 1/4 turn incre-
ments.
Review entire procedure before starting.
1. Clean the running belt and deck, see "Running Belt and Deck Cleaning Procedure"
on page280.
2. Switch the power OFF and unplug
1
the power cord.
3. Remove the front hood, see "Covers and Panels Replacement" on page86.
4. Remove the left and right trim landing covers, see "Covers and Panels Replacement"
on page86.
5. Legacy frame configuration:
Make sure that the left and right front Drive Roller Keeper(s) are installed.
Note:Some early production treadmills may only have one or no Roller keepers
installed. Install missing Roller Keepers as needed(PPP000000302495102 RIGHT
HAND ROLLER KEEPER, PPP000000302495102 LEFT HAND ROLLER
KEEPER).
1
Disconnect a device power cord plug or cable connector from the power receptacle or out-
let.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 68
5 Adjustment Procedures
Running Belt Tension and Tracking Adjustment
To Next Page
