6. Slowly relax the running belt tension using a 5/16" hex key driver and ratchet (only
use hand tools and not power tools). Alternately loosen the left and right adjustment
bolts in 1/4 turn increments so that the running belt tension is evenly relaxed.
Continue loosening the tension adjustment bolts until all tension is removed from the
belt and stop, do not remove the bolts.
Note:It is not necessary to remove the adjustment bolts. Loosen bolts until all ten-
sion is removed from the belt and stop. If the bolt was removed, remove the trim
end cap cover, and reinstall the bolt.
CAUTION:Only use hand tools to adjust tension. Power tools can easily over
and/or under tension causing damage to the belt and/or tension hardware mech-
anism.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 69
5 Adjustment Procedures
Running Belt Tension and Tracking Adjustment
