b. At this point the tension pressure has increased significantly and care must be
taken to not damage the adjustment hardware and/or belt. The tension gauge
will be used to determine when to alternate the left and right bolt tension adjust-
ment rather than the alternating 1/4 turn bolt method. Alternately adjust the left
and right side tension in increments of 0.2 (0.2%) gauge divisions until the man-
ufacturer tension specification is reached.
Running Belt Brand Specification
Ammeraal brand running belt tension (PPP000000303765103) 3.75 (0.75%)*
Forbo brand running belt tension (PPP000000302449101 or
PPP000000036355141)
3.55 (0.55%)*
Notes:*Referenced to gauge reading 3.0 (0.0%)
13. Remove the tension gauges.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 72
5 Adjustment Procedures
Running Belt Tension and Tracking Adjustment
