TECHNICAL INFORMATION
during the 2 minutes) once the following
parameters are met:
• Engine at idle;
• Oil at operating temperature;
• Transmission in neutral (N);
• Transmission output shaft stopped;
• Oil level sensor present and working.
After 2 minutes, the display will flash one of the
codes shown below:
CODE CAUSE OF CODE
OL-OK Oil level is correct
LO-01 One quart low
LO-02 Two quarts low
HI-01 One quart high
HI-02 Two quarts high
Note: Failure to meet one of the above
parameters will stop the two minute countdown.
One of the codes shown below will indicate the
cause of the countdown interruption. Once all
parameters are met, the countdown will continue
from where it left off.
CODE CAUSE OF CODE
CODE CAUSE OF CODE
OL-50 Engine speed (rpm) too low
OL-59 Engine speed (rpm) too high
OL-65 Neutral must be selected
OL-70 Sump oil temperature too low
OL-79
high
OL-89 Output shaft rotation
OL-95 Sensor failure
EXITING THE OIL LEVEL DISPLAY MODE
To exit the Oil Level Display Mode, press any
range button ("R", "N" or "D").
CLEARING CODES
If the CHECK TRANS light is illuminated, first
clear all diagnostic codes by pressing both the
"
" (up arrow) and " " (down arrow) push-
buttons at the same time, twice.
Take the vehicle for a test drive. If the CHECK
TRANS light illuminates again, record the
diagnostic codes. Refer to "World Transmission
(WT) Diagnostic Codes" under "Reading
Codes".
LIGHT BULB DATA
LIGHT BULB DATA
APPLICATION PREVOST
PART NO.
TRADE OR
SAE
NUMBER
WATTS OR
CANDLE
POWER
VOLTS QTY
EXTERIOR LIGHTING
Hi/Lo-beam 930291 9004 65/45 W 12 2
Docking & cornering 930319 9415 37.5W 12 4
Fog 561882 H3 (OSRAM) 55 W 12 2
License plate (sealed) 930266 TL 15206 --- 12 2
Side Lamp (red) 930340 Grote 47072-3 --- 12 12
Side Lamp (amber) 930341 Grote 47073 --- 12 12
Identification (red) 930334 25350R --- 12 6
Clearance (red) 930334 25350R --- 12 8
Identification (amber) 930337 25350Y --- 12 6
Clearance (amber) 930337 25350Y --- 12 8
8-19
