Chapter 8: TECHNICAL INFORMATION
DIMENSIONS AND
WEIGHTS
W0-40
W5-45
WE-45
Overall length
(over bumpers)
40’0”
(12,2 m)
45'
(13,7 m)
Overall width 102" (2,59 m)
Overall height 148 3/4" (3,78 m)
Wheelbase
(center of front axle
to center of drive axle)
280”
(7,11 m)
315"
(8,00 m)
Floor height from ground 48 1/2" (1,23 m)
Ground clearance 11" (280 mm)
Step height from ground 15" (380 mm)
Step height (other steps) 7” (178 mm)
Headroom 83" (2,11 m) STD
Entrance door opening
width
30" (762 mm)
Front overhang 69" (1,75 m)
Rear overhang
77½”
(1,97 m)
102 1/2"
(2,60 m)
Front track 85.9" (2,18 m)
Drive track 76.7" (1,95 m)
Rear track 83.6" (2,12 m)
Turning circle radius
(exterior front corner)
41'-5”
(12.6 m)
45’-7”
(13.9 m)
Curb weight
(before conversion)
N/A N/A
Gross Vehicle Weight
Rating (G.V.W.R.)
48,900 lbs
(22 200 kg)
Front axle Gross Axle
Weight Rating
(G.A.W.R.)
16,500 lbs (7 500 kg)
Drive axle (G.A.W.R.) 20,400 lbs (9 275 kg)
Tag axle (G.A.W.R.) 14,000 lbs (6 364 kg)
The Gross Vehicle Weight Rating (G.V.W.R.)
and the Gross Axle Weight Rating (G.A.W.R.)
for front, drive and tag axles are listed on a
certification plate located on the L.H. control
panel in driver's section.
CAPACITIES
W0-40
WE-45
W5-45
Engine oil
(in crankcase)
37 U.S. qts (35 l)
Engine oil
(in reserve tank)
8.4 U.S. qts (8,0 l)
Fuel tank
(legal capacity equal
to 95% of volume)
250 U.S.
gal. (945 l)
gal. (787 l)
plus
90 U.S.
gal. (opt)
Cooling system
18.7 U.S. gal. (71 l)
27.6 U.S. gal. (104,5 l)
Transmission
(does not include
external circuit)
10 U.S. gal. (38 l)
Differential oil 20 U.S. qts (18,7 l)
Power steering
reservoir
4.0 U.S. qts (3,8 l)
A/C compressor oil 4.5 U.S. qts (4,3 l)
Windshield washer
reservoir
5.3 U.S. gal. (20 l)
Refrigerant 24.1 lbs (11 kg)
FUEL TYPE
ASTM specification ................................... D-975
Recommended grade ................................... 1-D
Acceptable grade .......................................... 2-D
WHEELS AND TIRES
Steel wheels ........................................ 9” X 22½”
Aluminum forged wheels..................... 9” X 22½”
Except inner drive axle (steel) ....... 8.25” X 22½”
Tires ............................................. 315/80 R 22.5
RECOMMENDED TIRE INFLATION
PRESSURE AT MAXIMUM LOAD COLD)
The recommended tire inflation pressures are
given in the applicable documents supplied with
the vehicle. In addition, cold tire inflation
pressures are listed on the Department of
Transport's certification plate, affixed on the
8-1
