VEHICLE EXTERIOR
FRONT SERVICE COMPARTMENT 06394
EVAPORATOR COMPARTMENT
The HVAC (Heating, Ventilating and Air-
Conditioning) humidistat control is found in this
compartment.
EVAPORATOR COMPARTMENT 22178
The compartment door release latch is located
on the left side of the baggage compartment and
to the right of the HVAC compartment door. Pull
the release latch then swing the HVAC
compartment door open.
RECIRCULATION DAMPER IN HVAC COMPARTMENT
22175
Open or close the recirculation damper with the
lever shown in the illustration above
L.H. SIDE REAR SERVICE
COMPARTMENT
L.H. SIDE REAR SERVICE COMPARTMENT 22176
The rear electric compartment provides access
to the following:
• Coolant line shutoff valve;
• Coolant heater system.
The rear electric compartment door can be
locked/unlocked using the exterior compartment
key. The light in the compartment turns ON
automatically when the door is opened.
