CONTROLS AND INSTRUMENTS
CHECK TRANSMISSION INDICATOR
Illuminates briefly when the ignition
is switched ON as a light test. The
indicator light should go out after
two seconds.
When the "CHECK TRANS" indicator is
illuminated and the shift selector emits short
beeps for 8 seconds, the ECU is restricting
transmission shifting because special or
abnormal conditions are detected. The control
pad display will be blank.
If this happens, drive the coach to the next
available service station to receive assistance.
The ECU will not respond to shift selector
requests since operating limitations are being
placed on the transmission (i.e. upshifts and
downshifts may be restricted). Direction
changes and shifts to and from neutral (N) will
not occur.
Any time the CHECK TRANS telltale light
illuminates, the ECU will register a diagnostic
code. It may be identified on the display or by
using a diagnostic tool. Refer to "Technical
Information" chapter under "World Transmission
(WT) Diagnostic Codes", chapter 8.
Note: The CHECK TRANS indicator may also
illuminate when starting the engine in extremely
cold weather. Refer to "Starting and Stopping
Procedures" under "World Transmission (WT)
Warm-up", chapter 5.
Retarder Oil High Temperature Indicator
Illuminates when the transmission
oil temperature is too high.
Disengage the retarder to allow the
oil temperature to cool down.
Secondary Charge System Indicator
Illuminates when the secondary
alternator is not functional.
Fuel/Water Separator Indicator
06291
Illuminates when accumulated
water in the fuel filter/water
separator needs to be drained.
Refer to "Care and Maintenance"
chapter 7.
Level Low System Indicator
Illuminates when the vehicle
leveling system is activated.
Door Ajar Indicator
Illuminates when the central
entrance door (if equipped) is ajar.
Left Turn Signal Indicator
Flashes when the left turn signals
are activated. Signal right and left
turns by operating the multi-
function lever. See "Steering
Column Controls" in this chapter.
Window Open Indicator
Illuminates when a window is open
(hinged window only).
Retracted Tag Axle Indicator
06271
Illuminates when the tag axle is
retracted or unloaded. When the
tag axle is retracted, an alarm will
sound to warn the driver. The
control valve is located on the L.H.
lateral console.
STOP Engine Indicator
Illuminates when the ignition switch
is ON
as a light bulb and DDEC
system check. The indicator
should go OFF after five seconds.
If the indicator remains illuminated after five
seconds or comes ON sometime after starting
the engine, the DDEC system has detected a
major problem.
When a problem is detected, the engine power
will automatically begin to decrease gradually,
followed by full shutdown after 30 seconds.
The engine emergency shutdown may be
bypassed by using the " Engine Stop Override "
switch on the L.H. lower control panel.
3-16
