Procon V3D - Analogue Output Settings

H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 43 -
Submenu
Explanation, further submenus
Values
Default setting
Unit
5-1
analogue
output 1.
When selecting a motor parameter take care of its correct setting!
In case of feedback signal, the output displays the measured value related to 100%.
5-1-1 signal source
The parameter, to deliver a voltage or current
signal proportional to it, on the analogue OUT1
output.
Interpretation of the 100% values:
frequency 100Hz
Imotor In
Umotor Un
Udc 1000V
Unet 1000V
Pinp Pn
control ref. s. 100Hz
mod. cont. ref. s. 100Hz
reg. ref. s. 100%
mod. reg. ref. s. 100%
feedback 100%
error signal 100%
analogue IN 1,2,3,4 10V / 20mA
analogue IN 1-2,3-4 10V / 20mA
counter 1,2,3 10000
run time 1,2 1000h
heatsink 100C
n n sync.
n ENC n 100% (4-31-2)
torque Mn
Pbrake average 100%
Pbrake current 100%
frequency
Imotor
Umotor
Udc
Unet
Pinp.
control ref. s.
mod. cont. ref. s.
reg. ref. s.
mod. reg. ref. s.
feedback
error signal
an. IN1
an. IN2
an. IN3
an. IN4
an. IN1-2
an. IN3-4
counter 1
counter 2
counter 3
run time 1
run time 2
heatsink
n
n ENC
torque
Pbrake average
Pbrake current
frequency
5-1-2 range
For setting the interval used for the signalling the selected parameter of the source
5-1-2-1 maximum
0,0 - 1000,0
100,0
%
5-1-2-2 minimum
0,0 - 1000,0
0,0
%
5-1-3 features
voltage
current
voltage
5-1-4 voltage
5-1-4-1 upper
The output voltage value belonging to
5-1-2-1 maximum
0,0 - 10,0
10,0
V
5-1-4-2 lower
The output voltage value belonging to
5-1-2-2 minimum
0,0 - 10,0
0,0
V
5-1-5 current
5-1-5-1 upper
The output current value belonging to
5-1-2-1 maximum
0,0 - 20,0
20,0
mA
5-1-5-2 lower
The output current value belonging to
5-1-2-2 minimum
0,0 - 20,0
0,0
mA
5-2
analogue
output 2.
The setting is the same as that of item 5-1 analogue output 1.
