4.
Loosen 4 star screws on dosing head and remove with bearing
cover.
5.
Insert the rotor half supplied.
6.
If the surfaces of the two rotor halves are perfectly flush, place
bearing cover on dosing head.
7. Initially only loosely screw all 4 star screws into dosing head.
8. Manually tighten the 4 star screws. The domed nut must again be
screwed onto the 4th star screw and tightened to provide a locking
function.
9. Press the Clickwheel.
ð
The rotor turns slowly and the following appears:
‘ Please wait...’
.
The rotor stops and
‘Please change the tube!’
appears. Please
ignore this.
Initial commissioning
43
