AHD DVR User Manual
8

Itsupportsmousedrag.Takesettingupmotiondetectionareaforexample:Clickcustomized,
holddowntheleftbuttonanddragtosetmotiondetectionarea.



InPlayb ack : 
Clicktochoosetheoptions.Rightclicktoreturntolivemode.

InBackup:
Clicktochoosetheoptions.Rightclicktoreturntopreviouspicture.

InPTZContr ol:
ClickleftbuttontochoosethebuttonstocontrolthePTZ.Clickrightbuttontoreturntolive.

Note:Mouseisthedefaulttoolforalloperationsunlessanexception,asindicated.

3 BasicFunctionInstruction
3.1 PowerOn/Off
Beforeyoupowerontheunit,pleasemakesurealltheconnectionisgood.

3.1.1PowerOn
① Connectwiththepower.
② ThedevicewillbootandthepowerLEDwouldturnblue.
③ AWIZARDwindowwillpopupandshowsomeinformationabouttimezone,timesetup,
networkconfiguration,recordconfigurationanddiskmanagement.Usercansetuphere
andrefertotheconcretesetupstepsfromthecorrespondingchapters.Ifusersdon’t
wanttosetupWizard,pleaseclickExitbuttontoexit.PressandholdFN/ESCkeyto
switchtheresolutionofVGAandHDMIoutput.



