AHD DVR User Manual
17

Fig4‐7Live‐ColorAdjustment

5.2.2MainMonitor
Themainmonitorsettingsallowyoutosetcamerasequenceinlivedisplaymode.
Operatethefollowingstepstosetmainmonitor:
① GotoMainMenuSetupLiveMainMonitorinterface.RefertoFig4‐8.


Fig4‐8LiveConfigura tion ‐MainMonitor

② Selectdisplaymodeandchannel.
③ Selectdwelltime.Clickbuttontosetupthepreviouschannelgroupsofdwellpicture.
Clickbuttontosetthelatterchannelgroupsofdwellpicture.
④ Click“Apply”tosavethesetting.

5.2.3Mask
Ifthereissomethingyoudon’twanttodisplayintheliveimage.Youcansetmask.Foragiven
channelamaximumofthreeareascanbemasked.

