5.1 BasicConfiguration
Basicconfigurationincludesthreesubmenus:system,date&timeandDST.

5.1.1System
GotoMainMenuSetupBasicSysteminterface.RefertoFig4‐3.


Fig4‐3BasicConfiguration‐System

Inthisinterfaceyoucansetupthedevicename,deviceID,videoformat,maxnetworkusers,
VGAresolution,languageandsoon.Thedefinitionsforeveryparametersdisplayasbelow:
DeviceName:Thenameofthedevice.ItmaydisplayontheclientendorCMSthathelpuser
to
recognizethedeviceremotely.
DeviceID:ThisIDisusedtomapthespeeddomecameras.
VideoFormat:Twomodes:PALandNTSC.Usercanselectthevideoformataccordingtothatof
camera.
PasswordCheck:Ifthisoptionisenabled,theuserwouldneedtoinputtheusername
andthe
passwordforperformingcorrespondingoperations.
ShowSystemTime:Ifselected,thecurrenttimewillbedisplayedduringlivemonitoring.
MaxOnlineUsers:TosetthemaxnumberofconcurrentuserloginsintheDVR.
VideoOutput:Theresolutionoflivedisplayinterface.
Language:Setupthemenulanguage.

Note:Afterchangingthelanguageandvideooutput,thedeviceneedstologinagain. 

LogoutAfter(Minutes):Ausercansetupthescreenintervaltime(30s,60s,180s,300s).Ifthere
isnoanyoperationwithinthesettingperiod,thedevicewillautologoutandreturntologin
interface.
ShowWizard:Ifselected,theGUIwouldlaunchthestartupwizardoneveryboot,
allowingthe
usertodobasicsetup.
NoImage WhenLogout:Ifselected,therewillbenoimageshowingwhenloggingout.

