AHD DVR User Manual
4
2.2 Fr ontPanelDescriptions
Thefrontpaneldescriptionsareonlyforreference;pleasemaketheobjectasthestandard.

Notice:Thefrontpaneldescriptionsareonlyforreference;pleasemaketheobjectasthestandard.



MiniMetalCase(MM)

Item
Type
Name Description
1
Workstate
indicator
Power Powerindicator,whenconnection,thelightisblue
Net Whenaccesstonetwork,thelightisblue
REC Whenrecording,thelightisblue
2
Compound
button
Fn Changethedisplayoutputtype(LongPress)
3 IRreceiver IR Forremotecontroller
4 USB USBport
externalUSBdevices(USBflash,USBHDDforbackup,updatefirmware,
USBmouse)








Small1UCase

Frontpaneldescription:

Item
Type
Name Description
1
Workstate
indicator
Power Powerindicator,whenconnection,thelightisblue
HDD WhenHDDiswritingandreading,thelightisblue
Net Whenaccesstonetwork,thelightisblue
Backup Whenbackupfilesanddata,thelightisblue
Play Whenplayingvideo,thelightisblue
REC Whenrecording,thelightisblue


2
Compound
button
MENU/+
1.Entermenuinlive
2.Increasethevalueinsetup
BACKUP/‐
1.Decreasethevalueinsetup
2.Enterbackupmodeinlive
RECORD/FOCUS
1.Recordmanually
2.FOCUSfunctionenablesatPTZmode.
REW/SPEED 1.Rewindkey2.SPEEDfunctionenablesatPTZmode
1
2
3
4
