AHD DVR User Manual
5
Item
Type
Name Description
SEARCH/ZOOM
1.Entersearchmode
2.ZOOMfunctionenablesatPTZmode.
PLAY/IRIS
1.Enterplayinterface
2.IRISfunctionenablesatPTZmode
FF/P.T.Z.
1.Fastforward
2.EnterPTZmodeinlive
STOP/ESC
1.Quitplaymode
2.Exitthecurrentinterfaceorstatus
3
Inputbutton Directionbutton Changedirectiontoselectitems
Multi‐screen Changescreendisplaymodelike1/4/9channel
Enterbutton Confirmselection
4 IRreceiver IR Forremotecontroller
5
USB
USBport
externalUSBdevices(USBflash,USBHDDforbackup,updatefirmware,
USBmouse)
6
ExternalIR
EXT_IR ExtensionfortheIRreceiver








1UCase

Item
Type
Name Description
1


Workstate
indicator
Power Powerindicator,whenconnection,thelightisblue
HDD WhenHDDiswritingandreading,thelightisblue
Net Whenaccesstonetwork,thelightisblue
Backup Whenbackupfilesanddata,thelightisblue
Play Whenplayingvideo,thelightisblue
REC Whenrecording,thelightisblue


2







Compound
button
MENU/+
1.Entermenuinlive
2.Increasethevalueinsetup
BACKUP/‐
1.Decreasethevalueinsetup
2.Enterbackupmodeinlive
RECORD/FOCUS
1.Recordmanually
2.FOCUSfunctionenablesatPTZmode.
REW/SPEED 1.Rewindkey2.SPEEDfunctionenablesatPTZmode
SEARCH/ZOOM
1.Entersearchmode
2.ZOOMfunctionenablesatPTZmode.
PLAY/IRIS
1.Enterplayinterface
2.IRISfunctionenablesatPTZmode
FF/P.T.Z.
1.Fastforward
2.EnterPTZmodeinlive
STOP/ESC
1.Quitplaymode
2.Exitthecurrentinterfaceorstatus
3
DigitalInput
1‐10
1.Inputnumber1‐9orchoosecamera/Inputnumber0,10andtheabove
numbertogetherwithotherdigitalkeys
4

Inputbutton
Directionbutton Changedirectiontoselectitems
Multi‐screen Changescreendisplaymodelike1/4/9channel
Enterbutton Confirmselection
5 IRreceiver IR Forremotecontroller
6

USB
USBport
externalUSBdevices(USBflash,USBHDDforbackup,updatefirmware,
USBmouse)
7
ExternalIR
EXT_IR ExtensionfortheIRreceiver

