QSC TouchMix Series User Manual

127
1001108-01-F
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX Sub-Groups (odd) *
Sub-Groups (even) *
Aux (Even)
Meter
Ch Fader
Pre
Post
From DCA Masters
Digital
Gain
Pre
Post
Detector In
DAW*
Post Fdr
Pre Fdr
Pre Dyn
Pre all
Pre
Post
Patch Matrix*
Mute
Logic
Over
TouchMix-30: Ch 25 - 28
FX Send
Level
Record Pick-Off
(Global)
* TouchMix-30 only
Aux Send (Stereo)
Level
RTA
Assign
A/D
A/D
Top Panel Jack
SUM
SUM
Post Fdr
Pre Fdr
Pre Dyn
Pre all
SUM
TouchMix-30: Ch 29 & 30
TouchMix-16: Ch 17/18, 19/20
TouchMix-8: Ch 9/10, 11/12
SUM
Pre
Post
Aux Send (Mono)
Level
Input
Digital
DAW*
USB Drive
USB Drive
Recording Mode*
USB Drive
DAW*
Delay Low Cut High Cut PEQ
Gain
GainGate Comp
Mute
Balance
Width
Mute
Mute
Mute
Cue
To DAW*
Stereo Input Channels
