QSC TouchMix Series - FX Overview

80
1001108-01-F
FX O
Provides an overview of the channel FX Send and
Returnlevels.
FX sends and FX Master levels may be adjusted by
touching (selecting) the control then using the Master
Encoder or the Nudge buttons on a tablet device.
FX O S
NOTE: Only Input and Sub
Group banks are selectable on the
NavStrip.
1. Select an Input or Sub Group bank.
2. Each column (In 1, In 2 ...) represents a channel,
and lists the channel’s six FXSends.
3. Each row represents an FX mix, and lists the FX
Sends for the mix.
4. FX Master fader – Adjusts the overall
level of the effect that will be heard in the mix.
5. FX Processor Icon – Indicates the
currently selected FX device for the FX mix.
Press Menu
Touch FX
Overview
Menu
FX
Overview
1
2
4
5
3
