134
1001108-01-F
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX
Sub-Groups (odd) *
Sub-Groups (even) *
Aux (Even)
Meter
Ch Fader
Pre
Post
From DCA Masters
Mute
Logic
* TouchMix-30 only
RTA
Assign
SUM
Lush Reverb
Dense Reverb
Pitch Shift
Chorus
Mono Delay
Stereo Delay
Mute
Cue
Aux Send (Stereo)
Mute
Balance
Balance
Gain
Gain
PEQ
Low Cut
SUM
Aux Send (Mono, Odd Auxes)
Mute
SUM
Aux Send (Mono, Even Auxes)
Mute
FX Return
