QSC TouchMix Series User Manual

77
1001108-01-F
FX M − P
Recall presets for the selected FX channel based on the
current FX device.
1. Presets tab – Selects the Presets screen.
2. Current Preset – Displays the name of
the currently active preset (if any).
3. Save / Save As button – Displays
a page with options for naming a scene and
selecting internal or USB storage destination.
4. Factory list – Displays a list of the factory
programmed presets available for the currently
loaded FX device. Touch a preset name to select.
5. Mixer (internal) list – Displays a list
of presets that have been stored to Internal
mixermemory.
6. USB (external) list – Displays a list of
presets that have been saved on an External
(USB) drive.
7. Delete button – Deletes a selected preset
from Internal or External user memory.
8. Copy to USB button – Copies the
selected preset to an external USB Drive.
9. Copy to Mixer button – Copies the
selected preset to the internal mixer memory.
10. Recall button – Recalls the effects
parameters of a preset selected in the Factory,
Mixer or USB list. Recall does not affect Aux Sends, EQ, Mutes, or Group assignments.
Press Home
Touch
FXMasters
Select an
FX Channel
Touch
Presets
Inputs 1-8
FX 1
FX Masters
Presets
