QSC TouchMix Series User Manual

78
1001108-01-F
FX M − S
Rename the FX Master channel, and assign the channel
to Mute and DCA Groups
1. Setup tab – Selects the Setup screen.
2. Name field – Touch to display a keyboard
and enter a name for the channel.
3. Reset button – Returns settings to the
factory default.
4. Effect Pick-Off – Selects a pre or post-
fader pick-off point for the effect send.
5. Main L/R button – Turns the FX channel’s
assignment to the Main Left / Right output on
and off.
6. DCA Group Assignment Buttons
– Select the DCA Groups this channel is to be
part of. See the DCA Groupstopic.
7. Mute Group Assignment Buttons
– Select the Mute Groups this channel is to be
part of. See the Mute Groups topic.
Press Menu
Touch FX
Masters
Touch an
FX Channel
Touch
Setup
FX 1
Inputs 1-8
FX Masters
Setup
1
2 3
4
5
6
7
