1001108-01-F

8. Follow the directions and adjust the

-13.5 dB

Noise

Level

so that the RTA displays a moderate level of activity.

9. Touch

Measure

. The mixer produces the test signal and captures the measurement data.

NOTE:

Each output of a TouchMix mixer actually has two graphic equalizers. One is used by the Tuning Wizard to apply corrections

based on the measurement data. Settings for this equalizer are indicated by the outlined or “ghost” fader caps on the GEQ screen. The

other equalizer may be adjusted by the user.

10. Select a target tuning.

» Select

Flat

– The wizard ﬂattens the system response using the Tuning EQ and sets the user EQ to ﬂat. You

can adjust to taste from there.

» Select

Live

– The wizard ﬂattens the system response and applies a User EQ setting that works well for live

sound reinforcementsystems.

» Select

Keep Existing

– The wizard ﬂattens the system response using the Tuning EQ but leaves the user EQ settings

untouched.

11. Touch

Restart

if the measurement is interrupted by, for example, unexpected, loud ambient noise. Perform the

measurement again.

12. Touch

Finish

to continue.

13. Touch

Navigate To GEQ

to view the GEQ settings.
