36
1001108-01-F
TouchMix-8 TouchMix-16
External Control
3
TouchMix Control Apps
for iPad® and Android tablets controls most mixer functions.
for iOS® and Android smartphones controls personal monitor mix, rec/play, user buttons.
Requirements
iPad, iPhone (iOS 6 or later) / Android device (5.0 or later)
Wi-Fi
4
USB Wi-Fi adapter included
Dimensions (HWD) 56 mm x 333 mm x 245 mm (2.2” x 13.1” x 9.6”) 58 mm x 360 mm x 291 mm (2.3” x 14.2” x 11.5”)
Weight 4.3 lb (1.95 kg) 5.9 lb (2.98 kg)
Line Voltage Requirements 100 - 240 VAC, 50 - 60 Hz
Sampling Frequency Selectable 44.1kHz or 48kHz
Internal Processing 32-bit floating point
Latency <1.6msec, any input to any output
THD <0.005%, +4 dBu, 20 Hz - 20 kHz, unity gain, any input to any output
Frequency Response 20 Hz - 20 kHz +/-0.5 dB, any input to any output
Dynamic Range 105 dB
Equivalent Input Noise -126 dBu
Residual Output Noise -86 dBu
Crosstalk -80 dB
S/N Ratio -94 dB
Maximum Input Level +16 dBu (Mic/Line inputs, XLR), +26 dBu (Mic/Line inputs, TRS), +22 dBu (Stereo inputs)
Phantom Power 48V, individually switchable per channel
K & Lock® Security Slot
5
Compatible with the MicroSaver Security Cable
Included Accessories USB Wi-FI adapter, Soft Carrying Case, Power Supply
1 All TRS connectors are 1/4 inch.
2 A list of drives that have been validated by QSC may be found at qsc.com. The hard-drive market is huge and continuously changing so there are many
drives QSC has not validated that will work. Always test a new drive before using it for a critical session. Minimum requirement is USB 3.0 HD, SSD or
7200 RPM, FAT32 format.
3 The TouchMix App requires iOS 7 or higher.
4 Use only the Wi-Fi adapter supplied with your mixer.
5 Available on early production models of TouchMix-16.
