BIN Set and BIN Count
After setting the AUX_LO: -00000.0000 value, press the down [⇓] arrow key to view bins 1-4.
Press the down [⇓] arrow key again to view bins 5-8.
Press the [MAIN INDEX] key to return to the MAIN INDEX BINNING screen.
Press the [F4] = BIN COUNT to view the bin count for bins 1-8 and the OUT bin.
NOTE:
All bins can be viewed by pressing [F4] at anytime in [MAIN INDEX_BIN SET]
Move Backlit
Box: DOWN
Move Backlit
Box: DOWN
< MAIN INDEX BIN SET >
DIGIT UP
DIGIT DOWN
DIGIT
Increase value of underscored digit
Move underscore cursor to next digit
Decrease value of underscored digit
BIN
5
5
7
-000.00%
+000.00%
LO
F3
F1
F2
F4
Table: Bin 1-8 High and Low Values
HI
8
-000.00%
-000.00%
-000.00%
+000.00%
+000.00%
+000.00%
MAIN
INDEX
PRESS
F4
PRESS
< MAIN INDEX BIN SET >
DIGIT UP
DIGIT DOWN
DIGIT
Increase value of underscored digit
Move underscore cursor to next digit
Decrease value of underscored digit
BIN
2
1
3
-000.00%
+000.00%
LO
F3
F1
F2
F4
Table: Bin 1-8 High and Low Values
HI
4
-000.00%
-000.00%
-000.00%
+000.00%
+000.00%
+000.00%
SPEED:
TRIG.:
RANGE:
Change measurement speed: S/M/F
Change range: HOLD/AUTO
Change trigger: MAN/INT/EXT
BIN
2
0
3
127
BIN
F3
F1
F2
F4
Reset bin counts to 0.
COUNT
4
0
0
0
= BIN COUNT
COUNT M
MAN
AUTO
RESET
1
0
5
6
7
8
OUT
0
0
0
0
11
138TOTAL:
In the BIN COUNT screen:
Press [F1] = SPEED to change the measurement speed equal to Fast, Medium or Slow.
Press [F2] = TRIG to change the measurement trigger equal to MANual, INTernal or EXTernal.
Press [F3] = RANGE to change the measurement range equal to Hold or Auto.
Press [F4] = RESET to clear the contents of the bins.
Press [MAIN INDEX] when finished.
YES
NO
Do not clear the counts in all bins
Clear the Counts in all bins
BIN
2
0
3
127
BIN
F3
F1
F2
F4
COUNT
4
0
0
0
COUNT
1
0
5
6
7
8
OUT
0
0
0
0
11
138TOTAL:
To Next Page
