QuadTech 1730T User Manual

Page 80 of 110 150821/A4 Interface
3.1.5.2 CALCulate1:FORMat
Instruction: CALCulate1:FORMat
Parameter: {REAL⏐MLINear⏐CP⏐CS⏐LP⏐LS⏐ZS⏐RS⏐RP}
Return Value: {REAL⏐MLINear⏐CP⏐CS⏐LP⏐LS⏐ZS⏐RS⏐RP}
Function: Set or Query the primary measurement parameter.
Description: REAL Impedance, Real
MLINear Impedance, absolute value
CP Equivalent parallel capacitance
CS Equivalent series capacitance
LP Equivalent parallel inductance
LS Equivalent series inductance
ZS Equivalent series impedance
RS Equivalent series resistance
RP Equivalent parallel resistance
3.1.5.3 CALCulate2:FORMat
Instruction: CALCulate2:FORMat
Parameter: {IMAGinary⏐PHASe⏐D⏐Q⏐REAL⏐RS⏐XS}
Return Value: {IMAGinary⏐PHASe⏐D⏐Q⏐REAL⏐RS⏐XS}
Function: Set or Query the secondary measurement parameter.
Description: IMAGinary Impedance, Imaginary
PHASe Phase angle
D Dissipation factor
Q Quality factor
REAL Impedance, Real
RS Equivalent series resistance
XS Equivalent series reactance (imaginary)
Parameter SENS:FUNC:ON CALC1:FORM CALC2:FORM
Z – θ
R – X
“FIMPedance”
MLINear
REAL
PHASe
IMAGinary
Cp – D
Cp – Q
Cp – Rp
“FADMittance” CP
D
Q
Rp
Cs – D
Cs – Q
Cs – Rs
“FIMPedance” CS
D
Q
REAL
Lp – D
Lp – Q
Lp – Rp
“FADMittance” LP
D
Q
REAL
Ls – DCR
Lp – DCR
“FIMPedance”, “FRESistance”
“FADMittance”, “FRESistance”
LS
LP
REAL
REAL
L2 – N
L2 – 1/N
L2 – M
L2 – R2
“FIMPedance”, “VOLTage:AC”
“FIMPedance”, “VOLTage:AC”
“FIMPedance”, “FADMittance”
“FIMPedance”, “FADMittance”
LS
REAL
INV
LP
REAL
