24
5.2 Scorpion Backpack
The backpack is suitable for transporting all components that are required for a ight.
The battery packs must be carried in an extra bag.
Please unpack in the following order.
Layer Overview Outside Compartment
Outside Compartment
Main Layer
1. Skynav Tablet
2. Data link
handheld
Main Layer
3. Mainbody
4. Tailboom
5. Arm
left
7. Payload
8. Airspeed sensor
6. Arm right
Please follow the reverse order for packing and note that each part has a
symbol corresponding to the symbol in the transportation box.
