Page #21 background imageLoading...
Page #21 background image
5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 20 / 86
2.6. Pin Description
Table 4: Definition of I/O Parameters
The following table shows the pin definition and description of the module.
Table 5: Pin Description
Type
Description
AI
Analog Input
AO
Analog Output
AIO
Analog Input/Output
DI
Digital Input
DO
Digital Output
DIO
Digital Input/Output
OD
Open Drain
PI
Power Input
PO
Power Output
PU
Pull Up
PD
Pull Down
Pin
No.
Pin Name
I/O
Description
DC
Characteristic
Comment
1
CONFIG_3
DO
Not connected internally
2
VCC
PI
Power supply
Vmin = 3.135 V
Vnom = 3.7 V
Vmax = 4.4 V
3
GND
Ground
4
VCC
PI
Power supply
Vmin = 3.135 V
Vnom = 3.7 V
Vmax = 4.4 V
