5.1.4. Receiving Sensitivity
The following tables show conducted receiving sensitivity of RM500Q-AE and RM502Q-AE.
Table 33: RM500Q-AE&RM502Q-AE Conducted Receiving Sensitivity (Unit: dBm)
B66
1710–1780
2110–2200
B66
–
–
n66
B71
663–698
617–652
B71
–
–
n71
n77
3300–4200
3300–4200
–
–
–
n77
n78
3300–3800
3300–3800
–
–
–
n78
n79
4400–5000
4400–5000
–
–
–
n79
Mode
Frequency
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA
WCDMA B1
-109.5
-110.3
-110.5
-106.7 dBm
WCDMA B2
-109.5
-110.6
-110.5
-104.7 dBm
WCDMA B3
-109.5
-110.4
-110.5
-103.7 dBm
WCDMA B4
-109
-110.1
-110
-106.7 dBm
WCDMA B5
-110.5
-112
-112
-104.7 dBm
WCDMA B8
-109.5
-112
-111.5
-103.7 dBm
WCDMA B19
-111
-112
-112
-104.7 dBm
LTE
LTE-FDD B1 (10 MHz)
-98.0
-99.2
-101.0
-96.3 dBm
LTE-FDD B2 (10 MHz)
-97.0
-99.2
-101.5
-94.3 dBm
LTE-FDD B3 (10 MHz)
-97.0
-98.7
-101.2
-93.3 dBm
LTE-FDD B4 (10 MHz)
-97.5
-98.7
-101.0
-96.3 dBm
LTE-FDD B5 (10 MHz)
-99.0
-101.0
-102.5
-94.3 dBm
LTE-FDD B7 (10 MHz)
-97.0
-98.5
-100.5
-94.3 dBm
LTE-FDD B8 (10 MHz)
-98.5
-100.5
-102.2
-93.3 dBm
LTE-FDD B12(B17) (10 MHz)
-99.5
-101.5
-102.5
-93.3 dBm
