Quectel 5G Module Series Hardware Design

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 79 / 86
6.7. Operating and Storage Temperatures
Table 46: Operating and Storage Temperatures
1.
1)
To meet this operating temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module meets 3GPP specifications.
2.
2)
To meet this extended temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module remains the ability to establish and maintain functions such as voice*, SMS, etc., without
any unrecoverable malfunction. Radio spectrum and radio network are not influenced, while one or
more specifications, such as P
out
, may undergo a reduction in value, exceeding the specified
tolerances of 3GPP. When the temperature returns to the normal operating temperature level, the
module will meet 3GPP specifications again.
Parameter
Min.
Typ.
Max.
Unit
Operating Temperature Range
1)
-30
+25
+70
ºC
Extended Temperature Range
2)
-40
-
+85
ºC
Storage temperature Range
-40
-
+90
ºC
NOTES
