RM500Q-AE&RM502Q-AE_Hardware_Design 49 / 86
Table 21: RF Function Status
4.5.2. W_DISABLE2#
The module provides a W_DISABLE2# pin to disable or enable the GNSS function. The W_DISABLE2#
pin is pulled up by default. Driving it LOW will disable the GNSS function. The combination of
W_DISABLE2# pin and AT commands can control the GNSS function.
Table 22: GNSS Function Status
W_DISABLE1# Level
AT Commands
RF Function Status
High Level
AT+CFUN=1
Enabled
AT+CFUN=0
AT+CFUN=4
Disabled
Low Level
AT+CFUN=0
AT+CFUN=1
AT+CFUN=4
Disabled
W_DISABLE2# Level
AT Commands
GNSS Function Status
High Level
AT+QGPS=1
Enabled
High Level
AT+QGPSEND
Disabled
Low Level
AT+QGPS=1
Disabled
Low Level
AT+QGPSEND
