Quectel 5G Module Series Hardware Design

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 70 / 86
6 Electrical Characteristics and
Reliability
6.1. Power Supply Requirements
The typical input voltage of the module is 3.7 V, the following table shows the power supply requirements
of the module.
Table 39: Power Supply Requirements
6.2. Current Consumption
Table 40: RM500Q-AE&RM502Q-AE Current Consumption
Parameter
Description
Min.
Typ.
Max.
Unit
VCC
Power Supply
3.135
3.7
4.4
V
Voltage Ripple
–
30
100
mV
Voltage Drop
–
–
165
mV
Description
Conditions
Typ.
Unit
OFF state
Power off
82
μA
Sleep state
AT+CFUN=0 (USB Suspend)
5.11
mA
WCDMA @ DRX = 0. 64s, USB Suspend
5.389
mA
LTE-FDD @ DRX = 0.64s, USB Suspend
5.689
mA
